ARBOR’s New ARES-5300 Programmable Embedded Controller

ARBOR’s New ARES-5300 Programmable Embedded Controller
ARBOR Technology Corp. (Taiwan) – ARBOR Technology, a leading provider of embedded computing solutions, announces an addition to its extended-temperature box PC ARES series, the ARES-5300 programmable embedded controller. The fanless, cableless, modularized-designed unit features a power-efficient Intel® Celeron® J1900 quad-core SoC processor, rugged vibration and shock protection, and a wide operating temperature range (-22 ~ 140ºF). It is ideally suited for use in the harshest environments such as the oil and gas industries for such applications as oil rig control and systems monitoring.

The low-profile ARES-5300 is specifically designed for reliable operation under all conditions. The product features a wide range DC power input (9~36V), making it immune to power fluctuations. Other features include an mSATA socket, an outside-accessible CFast slot for faster control data, four external USB Type A connectors, one internal USB Type A connector for easy connection, as well as two RJ-45 Gigabit Ethernet ports.

The ARES-5300 is easy to install and maintain. The DIN Rail mounting kit allows 90 degree rotation, leaving all I/O ports easily accessible. In addition to its fanless, cableless and modularized design, the compact ARES-5300 measures just 70mm in depth and employs lightweight but strong aluminum alloy construction.

The ARES-5300 meets international standards such as CE, FCC Class A and UL 508.

For more information about this article from ARBOR Technology click here.
